Size: 185.2mm x 117.2mm x 32.8mm

Weight:

With Stand: 1036.6g

Without Stand: 869.1g

Size: 7"

Type: AMOLED

Aspect ratio: 16:9

Resolution (dot): 1920(W)x1080(H)

Brightness: 800nit

Contrast ratio: 100000:1

Color gamut: 100% NTSC

sRGB: 145%

DCI-P3: 105%

Color depth: 10-bit

PPI: 315

Refresh rate: 60Hz, 50Hz

Touchscreen: Capacitive

Viewing direction: All

Screen coating: Anti-fingerprint coating

HDMI:

Port: 4x HDMI 2.0 Type-A port

Typical Resolution/Frame rate:

4096x2160p/3840x2160p 23.98/24/25/29.97/30/59.94/60 (Only available for HDMI 1 and HDMI 2)

1920x1080p 23.98/24/25/29.97/30/50/59.94/60

1920x1080i 25/29.97/30

1280x720p 23.98/24/25/29.97/30/50/59.94/60

720x576p 50/100

720x576i 25/50

720x480p 59.94/60

720x480i 29.97/30

Color depth: 8/10/12-bit

Color sampling: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2

USB:

Port: 1x USB 3.0 Type-A port, 2x USB 3.0 Type-C port

Format: YUYV, MJPG, NV12, UYUV, RGB24, H.264

Resolution/frame rate: Up to 4K, 60fps

SRT Caller/Listener:

Codec: H.264, H.265

Resolution/frame rate: Up to 4K, 60fps

RTMP Pull/Push:

Codec: H.264

Resolution/frame rate: Up to 4K, 60fps

RTSP Stream:

Codec: H.264, H.265

Resolution/frame rate: Up to 4K, 60fps

NDI® Stream:

NDI HX2, NDI HX3, NDI High Bandwidth

Codec: H.264, H.265, SpeedHQ

Resolution/frame rate: Up to 4K, 60fps

Video:

Resolution: Up to 4K60

Codec: H.264, H.265

Format: MOV/MP4/WebM

Picture:

Format: JPEG/PNG/BMP

Webpage:

Supports adding up to 3 webpages as scenes and 7 webpages as GFXs

Mic/Line in: 2x 3.5mm jack, 2-channel, 48kHz, 16-bit

Audio input from HDMI port: Up to 8-channel, 192kHz, 24-bit

Audio input from USB port: Up to 8-channel, 192kHz, 24-bit

Audio input from Bluetooth device: 2-channel, 48kHz, 16-bit

Audio from SRT stream

Audio from RTMP stream

Audio from RTSP stream

Audio from NDI stream

Audio embedded in video files

Audio from a webpage

Background music (BGM): MP3, M4A, WAV files

Audio from GFXs: webpage, NDI and video

Audio from an App

Audio input from Phone Camera

Streaming and recording:

Codec: H.264, H.265

Resolution: 2160p, 1440p, 1080p, 720p, 540p, 360p*

* 360p is only available for NDI

Frame rate: 60/59.94/50/30/29.97/25/24/23.98/15 fps (Encoding options change along with the frame rate of the show.)

Bitrate:

NDI HX3: up to 110Mbps, down to 3Mbps

Others: up to 120Mbps, down to 256kpbs

Key frame interval: customizable

Profile:

H.264: High profile, Main profile, Baseline profile

H.265: Main profile

Level:

H.264: 5.2, 5.1, 5.0, 4.2, 4.1, 4.0, 3.2, 3.1, 3.0

H.265: 6.1, 6.0, 5.2, 5.1, 5.0, 4.1, 4.0, 3.1, 3.0

Bitrate mode: VBR, CBR

Color space: BT.709

USB-C OUT:

Port: 1* USB 3.0 Type-C port

Output mode: UVC 1.1/UAC 1.0, DP-OUT

Resolution: 3840x2160, 2560x1440, 1920x1080, 1280x720, 2160x3840, 1440x2560, 1080x1920, 720x1280

Frame rate: 60/59.94/50/30/29.97/25/24/23.98 fps

Sampling format: RGB24, YUYV, NV12, MJPEG

HDMI OUT:

Port: 2* HDMI 2.0 Type-A port

Resolution: 3840x2160, 2560x1440, 1920x1080, 1280x720

Frame rate: 60/59.94/50/30/29.97/25/24/23.98 fps

Sampling format: RGB 4:4:4, NV12

Streaming and recording: 2-channel, 16-bit, 48kHz, aac, 64kbps/96kbps/128kbps

Headphone output: 1x 3.5mm jack, 2-channel, 48kHz, 16-bit

Audio output via Bluetooth device: 2-channel, 48kHz, 16-bit

Audio output via USB-C port: 2-channel, 48kHz, 16-bit

Audio output via USB-A port: 2-channel, 48kHz, 16-bit/24-bit/32-bit

Audio output via HDMI OUT port: 2-channel, 48kHz, 16-bit

Connect to a USB A/V device, such as webcam, USB microphone, USB speaker, etc.

Connect to a USB modem

Connect to a mobile phone for USB tethering to share the phone’s mobile data connection

Connect to a USB flash drive

To transfer video, picture, audio and other media files, firmware update files, log files, etc.

Supported system format: FAT32, exFAT and NTFS

Connect to a USB keyboard for shortcuts

Nomal mode: Connect to USB devices, such as USB A/V devices, USB keyboard

DP mode: Connect to an external screen

Connection mode: Connect the device to a monitor with a USB-C to HDMI/VGA/DP adapter

A/V display mode options: Program, Preview, Multi-view, Duplicate Screen, Loop HDMI 1/2/3/4, Loop Webcam, Loop Stream

Image rotation: Rotate 90° to left, or rotate 90° to right

Supports using an external touchscreen to control the device in the Duplicate Screen mode

MTP mode: Connect to a PC to transfer video, picture, audio and other media files, firmware update files, log files, etc.

UVC + UAC mode*: Connect to a PC to output audio and video to streaming software

* To transfer video at full frame rate, please use a USB 3.0 cable to connect the USB 3.0 port of your computer.

Connect to an external screen

A/V display mode options: Program, Preview, Multi-view, Duplicate Screen, Loop HDMI 1, Loop HDMI 2, Loop HDMI 3, Loop HDMI 4, Loop App

Image rotation: Rotate 90° to left, or rotate 90° to right

Controlling the device via an external touchscreen: Connect the device with an external touchscreen via the HDMI OUT port and USB port and select the Duplicate Screen mode

Show:

Supports creating multiple shows in landscape (16:9) or portrait (9:16) mode, and manage them

Supports selecting quality: 1080p, 1440p, 2160p

Supports creating shows at 60/59.94/50/30/29.97/25/24/23.98 fps

Scenes:

Supports creating multiple scenes in a show, and managing them

Supports adding various sources, including HDMI, WEBCAM, video, picture, RTMP/SRT/RTSP/NDI stream*, webpage, document, app, text and color

* It supports adding up to 10 simultaneous live IP sources (SRT, RTMP, RTSP, NDI High Bandwidth, NDI® HX2, NDI® HX3) in one show.

Supports browsing and controlling webpage sources, document sources, and app sources

Supports multi-view composition in one scene, providing prebuilt layouts for easy creation

Provides lots of editing tools, including chromakey, crop, transition, etc.

Supports switch scenes directly or preview at first and then switch

Supports autoplay and VFA (Video-follow-audio) auto switch

Supports switching scenes with an instant cut or various effects, such as Fade, DIP, DVE, etc.

Audio:

Supports displaying level and peak through audio meter

Supports adjusting the level of each input audio, output and monitor audio

Supports global or scene-based settings for audio input sources

Supports AFV (Audio-follow-video)

Supports solo monitor

Supports switching monitor device

GFX:

Supports multiple GFX types, including title, lower third, animated text, digital clock, analog clock, bullet list, social media, logo, scoreboard, timer, stopwatch, etc.

Supports custom GFX with HDMI source, Webcam source, video, picture, text or PAG (Portable Animated Graphics) file

Supports webpage source as GFX

Supports NDI stream as GFX

Supports displaying multiple GFXs, and managing them

Supports controlling scoreboard, timer and stopwatch in real time

BGM

Supports adding BGM for each scene and controlling in real time

Supports adding global BGM via Web UI and controlling in real time

Pen

Annotates on the screen in real time

PTZ control:

Supports controlling PTZ camera via the network, supporting Visca UDP, supported sources including HDMI, WEBCAM (UVC camera), SRT stream, RTMP stream, RTSP stream and NDI stream

Replay:

Capture some of greatest moments, slow down the action and save highlights

Live stream:

Natively supports streaming to YouTube, Twitch and Facebook Live

Supports selecting RTMP or HLS protocol for streaming to YouTube

Supports starting a stream scheduled later for YouTube

Supports streaming via SRT, RTMP, RTMPS and RTSP protocols

Supports NDI HX3 output, supporting NDI Tally lights

Supports streaming to Restream

Supports customizing encoding parameters and selecting video source (Program, HDMI, WEBCAM, Multi-view) and audio source for ISO streaming

Supports streaming to four destinations simultaneously

Supports sending live comment as an overlay into the video feed when streaming to social media

Record:

Supports customizing encoding parameters

Supports ISO recording, to record four of different video sources simultaneously, or record multi-channel images with different quality for one source, combining different audio sources, and supported video sources include Program, HDMI, WEBCAM, Multi-view as well as IP stream

Supports saving recording files in MP4 or MOV format to local storage, SD card, or USB SSD

Supports saving screenshot files in PNG format to local storage, SD card, or USB SSD

Supports splitting recording files by time or size, up to 4 hours or 16G

Supports exporting or downloading files through computer, SD card, USB flash drive, App, or Web UI

Shortcut:

Supports connecting USB or Bluetooth keyboards and creating shortcuts for easy control

Supports Ethernet, WiFi and Cellular

Ethernet: 1x RJ45 port, 10/100/1000/2500 Mbps Base-T

Wi-Fi: 2.4G/5G/6G, Station and Hotspot modes supported

Cellular:

1* 5G SIM card slot

USB modem supported (not supplied)

Supports Bluetooth for audio input or output with Bluetooth devices, and also supports Bluetooth keyboard, etc.

Bluetooth: BT 5.3

Supports USB tethering to share the Internet data connection of a mobile phone by connecting the phone with the device through a USB cable

Local storage: 128 GB

microSD card (not supplied): FAT32 (Under 128G), NTFS, exFAT

AC power

Power input: 12V/5A

Battery pack

2x DC 7.4V (NP-F battery packs, not supplied)

Hot swappable

Power consumption:

No-load: ≈14W

Full-load: ≈29W

Each battery has four LED lights which can be set as battery indicators or NDI tally lights.

Battery indicators (default)

4* Green: 75% - 100%

3* Green: 50% - 75%

2* Green: 25% - 50%

1* Red: <25%

Off: depleted

NDI tally lights

Red: the NDI streaming signal is in PGM view.

Green: the NDI streaming signal is in PVW view

Operating temperature: –10 to 50 deg C (AC power)

Storage temperature: –20 to 70 deg C

Relative humidity: 5% to 90% non-condensing
